Ultimatron Lithium Battery 36V 100Ah LiFePO4 Smart BMS With Bluetooth
Original price was: 1.156,00€.851,00€Η τρέχουσα τιμή είναι: 851,00€.
– 5-year manufacturer warranty
– The safest technology , without risk of fire or explosion
– A long lifespan
– Constantly improving storage capacity
– High stability even under extreme loads
– No memory effect , no need for full charge and discharge cycles
– High performance even if extreme conditions
– Deep and steady discharge and charge efficiencySmall size and light weight
Διαθέσιμο κατόπιν παραγγελίας
Technical sheet
Nominal voltage 38.4 V
Nominal capacity 100 Ah
Capacity @ 20A 300 min
Energy 3840 Wh
Resistance ≤10 mΩ @ 50% SOC
Self-discharge <3% / Month
Number of Cycles >6000 at 80% DoD
Maximum Continuous Discharge Current 150 A
Peak discharge cut-off current 500A±60A(250-1000ms)
Discharge Cut-off Voltage 30 V (2000 ms)
Reconnection Voltage >33.6V
Short Circuit Protection 1400A ± 160A
Discharge Temperature -20 ~ 55 ºC
Charging Temperature 0 ~ 55 ºC
Storage temperature -20 ~ 35 ºC
Recommended Charging Current 20 A
Maximum Charge Current 50 A
Recommended Charging Voltage 43.8 V
Charge Cut-off Voltage 43.8 V(2000 ms)
Reconnection Voltage >41.4V
Equilibrium voltage >38.4 V
Dimensions (L x W x H) 522x 240 x 218 mm
Weight 28.5 kg
Connection screw M8
Torque terminals 80 ~ 100 in-lbs (9 ~ 11 Nm)
Material Box ABS
Protection IP65
Certifications CE
UN38.3
UL1642 & IEC62133
Shipping classification UN 3480, CLASS 9
