Charge Controller 12-24V10A with 3 Charge stages. Simple, economical and reliable Charge Controller, able to transfer the Charge from photovoltaics to batteries correctly, for a long life of the same. A charged batteries the Regulator stops the Charge and maintains the optimum voltage for the battery type selected, avoiding overloads and damage.
Output to the load at low voltage Timer.
Suitable for photovoltaic panels with 36 or 72 cells in mono or polycrystalline silicon up to 180 watts.
Always check the parameter Im solar panel if it is compatible with the maximum allowable current from the Regulator.
Régulateur de charge 12/24V 10A PWM Light BlueSolar – Victron Energy
37,00€
Voltage configurations: 12-24V;
– Rated charging current: 10A;
– Load max voltage: 14,4/28,8V;
– Charge disconnection point: 11/22V – adjustable from 9 to 12V (18-24V);
– Charge re-connection point: 12,6/25,2V – adjustable from 13 to 15V (26-30V);
– Battery Over Voltage Protection: 16.5V/33V;
– Charge system: 3 stages;
– Working temperature: -20/+55°C;
– Protection: IP32;
– LCD display: SI;
– Dimensions: 168x92x41.5mm;
– Weight: 320g.
Σε απόθεμα (επιπλέον μπορεί να ζητηθεί κατόπιν παραγγελίας)
9
βλέπουν το προϊόν αυτό τώρα!
Περιγραφή
Επιπλέον πληροφορίες
| Βάρος | 0,300 κ. |
|---|---|
| Διαστάσεις | 150 × 50 × 100 cm |
Σχετικά προϊόντα
Solar Laderegler 60A SC60ALCD 2xUSB 12/24V
SKU:
LR60ALCD
Original price was: 80,00€.45,00€Η τρέχουσα τιμή είναι: 45,00€.
Régulateur de charge 50A MPPT 100/50 SmartSolar – Victron Energy
