Battery Type Lead-carbon
Nominal Voltage 12V
Nominal Capacity 200Ah
Design life 15 years
Terminal M8
Approx. Weight Approx 62.5kg (137.8lbs)
Container Material ABS
Rated Capacity 200Ah 10Hour Rate (20.0A to 10.8V)
163Ah 3Hour Rate (54.2A to 10.8V)
132Ah 1Hour Rate (132A to 10.5V)
Internal resistance Full charged at 25˚C: 2.9 mΩ
Max. Discharge Current 2400A(5S)
Operating Temperature Discharge: -40 ~60℃(-40~ 140˚F)
Charge : -20 ~50℃(-4~ 122˚F)
Storage: -20 ~50℃(-4~ 122˚F)
Charge Method (25 ˚C) Charge current: Max.100A；Recom.20~40A
Float Charge voltage(-3mV/℃）: 13.5-13.8V,recom.13.5V(Full floating system) 13.5-13.8V,recom.13.62V(Cycle use system)
Equalize charge:13.8-14.1V,recom.14.1V(-4mV/ ˚C)
Cycle charge:14.4-15.0V,recom.14.4V(-5mV/ ˚C)
Self discharge 3% of capacity declined per month at 25˚C
