Battery Type GEL
Nominal Voltage 12V
Nominal Capacity 100Ah
Design life 12 years
Terminal M8
Approx. Weight Approx 29.5kg (65.0lbs)
Container Material ABS
Rated Capacity 100Ah 10Hour Rate (10.0A to 10.8V)
48.9Ah 3Hour Rate (26.3A to 10.8V)
64.2Ah 1Hour Rate (64.2A to 10.5V)
Internal resistance Full charged at 25˚C: 5.2 mΩ
Max. Discharge Current 1200A(5S)
Operating Temperature Discharge: -40 ~60℃(-40~ 140˚F)
Charge : -20 ~50℃(-4~ 122˚F)
Storage: -20 ~50℃(-4~ 122˚F)
Charge Method (25 ˚C) Charge current: Max.25A；Recom.10A
Float Charge voltage(-3mV/℃）:
13.5-13.8V,recom.13.5V(Full floating system)
13.5-13.8V,recom.13.62V(Cycle use system)
Equalize charge:13.8-14.1V,recom.14.1V(-4mV/ ˚C)
Cycle charge:14.4-15.0V,recom.14.4V(-5mV/ ˚C)
Self discharge 3% of capacity declined per month at 25˚C
